Product Overview
Mars 01127 3.3 Refigeration Motor 1/12-1/15-1/20HP 115-230V 1550RPM Replaces Packard 49101
Replaces hundreds of OEM shaded pole evaporator fan motors found in Bohn, Nutone, Chandler, Larkin, Kramer, Climate Control, McQuay, Heatcraft and reduce truck stock costs
- Motors delivers more power and lower amp draw compared to shaded pole
Motor Type
PSC
Enclosure
Open
H.P. (Max.)
1/12
Voltage
115/230
Multi-Rated H.P.
1/12,1/15,1/20
Speeds
1
Hz
60
Rotation
REV
RPM Range
1550
NEMA Frame Size
3.3 Stud
Phase
Single
Standards
CUL
FLA
1.1
Mount
All Angle
Bearing
Sleeve
Shaft Length Inches
3
Shaft Dia Inches
1/3
Thermal Protection
Auto
Ambient Deg C
60
Ins. Class
Class B
Capacitor Included
Yes
Capacitor Rating
7.5/370
Brand
MARS
Pack Qty
1
Case Qty
1
Pallet Qty
144
Length
8.60 in.
Width
5.20 in.
Height
5.40 in.
Weight
4.1000 lbs
Harmonized Tariff Code
8501402040
UPC
685744011279
Country of Origin Code
CN
Country of Origin Name
China
