Halco 55142 M57/175CWA/5T/K 175W MH M57/H39 5T KIT

Halco

(No reviews yet) Write a Review
$51.99
SKU:
55142
UPC:
807154551422
Availability:
SHIPS SAME DAY, 1 OR 2 DAY PRIME SHIPPING,BULK PRICING AVAILABLE
Weight:
8.10 LBS
Shipping:
Free Shipping
Bulk Pricing:
Buy in bulk and save
SHIPS:
SAME DAY
AVAILABLE FOR PICK UP IN:
Atlanta, Chicago, Cleveland, Houston, Phoenix, S California
2 DAY DELIVERY:
MOST LOCATIONS
1 DAY DELIVERY TO:
Atlanta, Chicago, Cleveland, Houston, Phoenix, S California
Adding to cart… The item has been added

Product Overview

Halco 55190 750W CWA M149 5-TAP 120V, 208V, 240V, 277V, 480V MP CORE & COIL BALLAST

ANSI Code 1  M149
 Applications  Roadway, Parking lot, Retail, Security, Street, Wall Wash
 Ballast Type  Pulse Start Metal Halide
 Brand  ProLume
 CSA  N
 Capacitor Included  Y
 Case Height  4.25
 Dimmable  N
 Fuse Rating-120V (Amps)  20
 Fuse Rating-208V (Amps)  10
 Fuse Rating-240V (Amps)  10
 Fuse Rating-277V (Amps)  8
 Fuse Rating-480V (Amps)  6
 HTS code  8504100000
 Inner UPC  807154551903
 Input Frequency (Hz)  60
 Input Short Circuit Current-120V (Amps)  2.0-6.0
 Input Short Circuit Current-208V (Amps)  1.2-3.6
 Input Short Circuit Current-240V (Amps)  1.0-3.0
 Input Short Circuit Current-277V (Amps)  0.9-2.7
 Input Short Circuit Current-480V (Amps)  0.5-1.5
 Input Volts (V)  120/208/240/277/480
 Lamp Type  HID Ballast
 Lamp Wattage  750
 Markets  Commercial, Industrial
 Nominal Open Circuit Volts  371
 Number of Lamps  1
 Open Circuit Current- 120V (Amps)  5.6
 Open Circuit Current- 208V (Amps)  3.2
 Open Circuit Current- 240V (Amps)  2.8
 Open Circuit Current- 277V (Amps)  2.5
 Open Circuit Current- 480V (Amps)  1.6
 Operating Current-120V (Amps)  7.2
 Operating Current-208V (Amps)  4.1
 Operating Current-240V (Amps)  3.6
 Operating Current-277V (Amps)  3.1
 Operating Current-480V (Amps)  1.8
 Primary Lamp  MH750
 Product Code  M149/750CWA/5T/K
 Product Description  750W CWA M149 5-TAP 120V, 208V, 240V, 277V, 480V MP CORE & COIL BALLAST
 Product Number  55190
 SS BUY PKG  1
 Secondary Short Circuit Current - 120V (Amps)  4.0-6.1
 Secondary Short Circuit Current - 208V (Amps)  4.0-6.1
 Secondary Short Circuit Current - 240V (Amps)  4.0-6.1
 Secondary Short Circuit Current - 277V (Amps)  4.0-6.1
 Secondary Short Circuit Current - 480V (Amps)  4.0-6.1
 Specification Sheet
 Start Type  Pulse Start
 Starting Current - 120V (Amps)  4
 Starting Current - 208V (Amps)  2.4
 Starting Current - 240V (Amps)  2.1
 Starting Current - 277V (Amps)  1.8
 Starting Current - 480V (Amps)  1.2
 Warranty (Yrs)  2
 Wattage (W)  810
Capacitance (mfd)  24
 Capacitor - Minimum Voltage  480
 Capacitor Diameter (In)  1.88
 Capacitor Height (In)  3.94
 Case Height  4.25
 Case Length (In)  6
 Case Width (In)  2.84
 Circle E  Y
 Circuit Type  CWA
 ETL  N
 Ignitor Included  Y
 Inner UPC  807154551903
 Lead Length - HID  12
 Maximum Case Temperature (F)  90
 Minimum Start Temperature (F / C)  -22 / -30
 RoHS Compliant  Y
 SS BUY PKG  1
 UL  Y
 UL Bench Top Rise Code  A/A/A/A/A
 UNSPSC  39101902
 Warning 1  Install in accordance with National Electrical Code
 Warning 2  Ground Ballast Core and Metallic Capacitor Case
 Weight (lbs)  20.28
 Weight - Ballast (lbs.)  20.28
 Weight - Total Kit (lbs)  20.28
 cUL  Y
