Product Overview
Eaton Wiring Devices 65W49BK Recp Single WT 15A 250V 2P3W H/L BK
Eaton Arrow Hart watertight locking receptacle, #18-10 AWG, 15A, Industrial, 250V, Back wiring, Black, Single, Watertight, L6-15, Two-pole, Three-wire, grounding, Thermoplastic, glass-filled nylon
Eaton's Arrow Hart watertight locking devices utilize a unique, robust design and superior materials to provide watertight security in harsh environments.
| Allowable Wire Size | #18-10 AWG |
| Amperage Rating | 15 A |
| Application | Industrial |
| Color | Black |
| Contact Material | Nickel plated bronze |
| Design Type | Single receptacle |
| Device Grade | Extra heavy-duty industrial specification grade |
| Environmental Resistance | NEMA 3 | NEMA 3R | IP66 | NEMA 12 | NEMA 4X | NEMA 4 |
| Face/Body Material | Glass filled Nylon |
| Material | Thermoplastic, glass filled nylon |
| Nema Configuration | L6-15 |
| Number Of Poles | Two-pole |
| Number Of Wires | Grounding | 3 |
| Receptacle Type | Locking |
| Special Features | Watertight |
| Torque rating | For #10-14 AWG: 14-16 lbf-inch. For #8 AWG: 20 lbf-inch |
| Type | Locking receptacle |
| Voltage Rating | 250 V |
| Wiring Method | Back |
| Length | 6.75 IN |
| Width | 4.25 IN |
| Height | 4 IN |
| Volume | 114.75 CI |
| Weight | 0.78 LB |
| Length | 6.75 IN |
| Width | 4.25 IN |
| Height | 4 IN |
| Weight | 0.78 LB |
