Product Overview
Marathon S102 General Purpose Motor 1/4 1725 DP 48 1/60/115
Description:
| Identification | |
|---|---|
| PEMS Number | M4701 |
| Brand | Marathon |
| Catalog Number | 4701 |
| Category | Motor |
| Class | Fan and Blower Motor |
| Country of Origin | Mexico |
| UPC Number | 722856039293 |
| Specifications | |
|---|---|
| Electrical Type | Split Phase |
| Phase | 1 |
| Frame | 48Y |
| HP | 0.25 |
| Speeds | 1 |
| Enclosure | Open Enclosed |
| Voltage | 115 |
| RPM | 1725 |
| Material | Rolled Steel |
| Efficiency | 51.9 |
| Rotation | CCW/CW |
| Amps | 5.1 |
| Frequency | 60 |
| Service Factor | 1.35 |
| Overload Protector | Automatic |
| Certifications | |
|---|---|
| CE | No |
| CSA | Yes |
| UL | Recognized |
| Shaft | |
|---|---|
| Diameter (in) | 0.500 |
| Extension (in) | 1.5 |
| Frame | |
|---|---|
| Length (in) | 5.41 |
| Size | 48 |
| Suffix | Y |
| Mounting | |
|---|---|
| Type | Resilient Base |
| Orientation | ANY |
| Thru-bolts Extension | 0 |
| Dimensions | |
|---|---|
| Weight (lb) | 12.00 |
| C (in) | 8.94 |
Features
- Duty: Continuous
- Ambient (Celsius): 40
- Insulation Class: B
- Poles: 4
- Starting Type: SM
- KVA Code: P
About This Product
Automatic reset thermal protector prevents overheating.
Patented MAXGuard insulation system offers superior protection for use with a variable frequency drive.
Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
Ambient temperature up to 70 allows for consistent operation in a range of environments and applications.
Vertical/horizontal mounting for proper placement of the fan within airflow.
